Universal screw-cutting lathe RYAZAN 165 testing under power
Автор: EMTC Machinery
Загружено: 2022-09-01
Просмотров: 217
Описание:
Universal screw-cutting lathe RYAZAN 165
YOM: 1975
Manufacturer: Ryazan
Made in: Russia
Specification:
Max. work-piece diameter:
-Above bed: 1000 mm
-Above support: 600 mm
Max. work piece length: 3000 mm
Max. work piece weight: 5000 kg
Diameter of a cylindrical aperture in a spindle (not less): 85 mm
The end of a spindle in accordance with GOST 12595-72: 1-15M
Cutting tool height: 50 mm
Amount of speeds of a spindle: 24
Spindle speed: 5-500 rpm
Feeds count: 32
Feeds:
-Line: 0,20-3,05 mm/turn
-Cross: 0,07-1,04 mm/turn
The greatest force of cutting supposed by the mechanism of submissions:
-Longitudinal: 1200 kg
-Transverse: 780 kg
Step of a cut groove:
-Metric: 1-120 mm
-Modular module: 0.5-30
-Inch: 28-1/4 threads/inch
Machine overall dimensions:
-Length: 5825 mm
-Width: 2100 mm
-Height: 1760 mm
Machine weight: 12500 kg
Offer #2202
More offer in our website: www.emtc.lt
