Turbo Rx7 build EP4: FC S4 Turbo II transmission synchro replacement

Описание: ** UPDATE!! 8/6/25 ** Well it's been in there for over a year now, and as far as the gears go, no issues what soever. I am driving it pretty hard on the street too. I did have the lockout for 5th and reverse gears ball and spring backwards up near the shifter, but it was a super quick fix. So good to have synchro's again.

1987 Turbo RX7 S4 Transmission synchro replacement. This is not a definitive guide, but more or less the process I did to replace the synchro's. Whether this transmission is now junk or not only time will tell. This is about half the cost of a rebuild from a shop, so definitely not super cheap. I don't have a manual transmission shop near me, and I didn't want to wait or mess about with shipping.
Rebuild Technical manual I followed = Non-Turbo and Turbo FC: https://www.rotaryheads.com/PDF/2nd_g...

Parts used:
BK199WS transmission rebuild kit with bearings $375
https://transpartswarehouse.com/bk199...
(5th gear synchro in this kit is too small, mine was still good and was not replaced)
Grey RTV: fuel and oil resistant $5
Tools needed:
*10mm, 12mm, 14mm,17mm, 19mm, 21mm, 27mm and 41mm sockets
$20 https://www.amazon.com/dp/B07DCZ8FGL?...
**41mm has to be cut in half and welded to a pipe to reach about 2 feet.
*Harbor freight ICON bearing puller (modified with 11" extensions, recommend 14") $200
https://www.harborfreight.com/master-...
*Harbor freight pulley puller; ground down to 6.5mm width $40
https://www.harborfreight.com/automot...
*Welder
*Cut off wheel to cut 41mm socket and pipe
*Angle grinder to modify pulley puller width
*Lock ring pliers $15
*Snap ring pliers $30
https://www.amazon.com/dp/B092C7FZJW?...
*Needle nose pliers
*Pick set
*Vise-grip 6 inch locking C-Clamp
*Impact gun/Air impact gun to break the bolts free
*Torque wrench
*punch set
*Map gas/propane torch
*Screw drivers
*Rubber Mallet
*Brass hammer
*Hammer
*Many plastic bags, ID tags and preferably some way to film yourself in case you get mixed up.
**Hydraulic press, not used in this video but recommended

*****You should probably follow the manual and use feeler gauges and dial calipers to measure clearances and offsets. I didn't have spare shims or washers so I replaced the synchro's and bearings without measuring. I wouldn't recommend this, and It will probably be why the transmission fails, if it does.
