BB-2 – Metal Gauge | Blueprint Bootcamp

Описание: This Blueprint Bootcamp workout drills in repeated dimensions — how to spot them, why they matter, and how to keep your prints clean and readable when the same feature shows up multiple times. The part you’ll work with is a simple metal gauge plate, perfect for sharpening your blueprint-reading accuracy and speed.

You’ll practice:
✅ Identifying repeated dimensions on a print
✅ Reading parts with symmetrical or patterned features
✅ Staying efficient when dimension callouts repeat

Challenge Questions:
💬 What’s the best way to avoid double-counting repeated dimensions?
💬 How can symmetry simplify your blueprint layout?

📄 Download the printable PDF drawing:
➡️ https://drive.google.com/file/d/1QN2w...
