Here's a comprehensive guide on how to use the BTS7960 motor driver with an Arduino Uno:

Understanding the BTS7960 Motor Driver:-

The BTS7960 is a high-power motor driver module capable of driving loads up to 43A with built-in overheating and overcurrent protection.
It supports bidirectional control of two DC motors or a single stepper motor.

Wiring Connections:-

Connect the power supply (Vcc) to the motor driver. Ensure it's within the operating voltage range (5V to 27V).
Connect the ground (GND) of both the power supply and Arduino to the motor driver.
Connect the outputs (OUT1, OUT2) of the motor driver to the terminals of the DC motor(s).
Establish connections between the Arduino and the motor driver:
Arduino pin 2 (IN1) to motor driver pin INA.
Arduino pin 3 (IN2) to motor driver pin INB.
Arduino pin 4 (PWM) to motor driver pin PWM.

Material Required:-
1. Arduino Uno
2. Bts7960 Motor Driver
3. Dc 12v Gare Motor
Source Code- https://drive.google.com/file/d/1CJVb...
