Reviving and old DX11 video card (AMD Radeon HD 5770)
Автор: Good Old Soldering Iron
Загружено: 2022-12-08
Просмотров: 522
Описание:
We used just two resistors to get another video card to work, by fixing the PEX_RESET and power up sequencing circuits.
00:00:00 The TLDW
00:00:21 The adventure starts with the auction site
00:00:54 Visual inspection of the board
00:01:08 Resistance checks
00:01:25 First time powering it up
00:01:41 PEX_RESET woes
00:03:27 PEX_RESET fixed, but does it work?
00:03:57 Power-up sequence needs work
00:08:00 Does it work now?
Music tracks:
Bliss Of Heaven - SOMM [Audio Library Release] (Music provided by Audio Library Plus)
bensound - summer (www.bensound.com)
Repair of the Asus Phoenix DDR4 GT 1030:
• The easy repair of a DDR4 GT 1030
Repair channels:
/ learnelectronicsrepair
/ @necro_ware
/ techcemetery
/ thecod3r
More resources (schematics, datasheets, PCB pictures):
https://drive.google.com/drive/folder...
