Replacing Engine Mounts: 4WD 2004-2008 Ford F150 WITHOUT removing Manifold/Exhaust | SUPER DIY

Описание: The space is tight, but it's possible. Just watch the how-to guide. This is useful for 2004-2008 model year F150 trucks. This truck is a 4wd (or 4x4) 4.6L V8 F-150. This is the same for the 5.4L Triton except a few small details like throttle body needs to be removed on the 5.4L. If you need to find a specific part of the video, click or tap on the time stamps below so you can quickly navigate through the video to find what you need. The engine/motor mounts on the 2wd is the same, but easier.

Buy the front left engine mount Anchor# 3206 (2008 F150 4.6L V8)
https://araparts.com/engine/engine-mo...

Buy the front right engine mount Anchor# 3207 (2008 F150 4.6L V8)
https://araparts.com/engine/engine-mo...

Buy the transmission mount Anchor 3136 (2008 F150 4.6L V8 **4WD ONLY**)
https://araparts.com/manual-transmiss...

Buy the transmission mount Anchor 2844 (2008 F150 4.6L V8 **RWD ONLY**)
https://araparts.com/manual-transmiss...

Oil pan: I suggested a 4x4 block of wood, which will work, but a 4x6 or larger surface would be MUCH better for lifting by the oil pan.

Oil Pan replacement video:    • 2004-2008 Ford F150 4.6L V8 2v 4wd Oil Pan...

I ended up bending the oil pan from improperly supporting it from only one edge. I was impatient and thought that I can lift the engine without removing the crossmember. When the crossmember is removed, there is enough room to properly support the engine from the oil pan.

Video Guide timestamps (Click/tap to navigate)

https://www.araparts.com

Video Guide/Time stamp
Oil Pack/Engine support recommendations: 1:39 & 5:06
Jack Stand Position 2:32
Removing engine parts before lifting engine: 2:47
Oil Pack/Engine support recommendations:
Viewing left mount bolts: 4:19
Removing 24mm big bolt for left mount 7:16
Left mount plate 13mm bolts location/removal: 7:48 & 9:22
Transmission mount bolts loosen: 8:50
Dipstick removal: 9:44
Actually removing left engine mount: 10:03
Nut that 24mm big bolt threads in to: 10:28
Separating Mount from mount plate: 10:44
Left mount install: 11:13
Dipstick install: 12:11
Starter removal (disconnecting battery first): 13:01
Right mount plate 13mm bolts location/removal: 15:07
Actually removing right mount: 16:01
Right mount install: 16:47
