KEARNEY & TRECKER MODEL 650 VERTICAL MILLING MACHINE: STOCK
Автор: YODER MACHINERY
Загружено: 2025-05-21
Просмотров: 485
Описание:
YODER MACHINERY SALES
MODEL ................................ 650-20 TF
AREA OF TABLE ........................ 106" X 19-1/2"
SPINDLE SPEEDS ....................... (24) 15 TO 1500 RPM
LONGITUDINAL & CROSS FEEDS ........... (32) 3/8 TO 90 IPM
VERTICAL HEAD ........................ (32) 3/16 TO 45 IPM
VERTICAL KNEE FEEDS .................. (32) 1/8" TO 30 IPM
LONGITUDINAL TABLE TRAVEL ............ 60"
CROSS TABLE TRAVEL ................... 18"
VERTICAL TRAVEL OF KNEE .............. 16"
VERTICAL TRAVEL OF HEAD .............. 8"
DISTANCE SPINDLE TO TABLE ............ 0" MINIMUM TO 22" MAXIMUM
SPINDLE TAPER ........................ #50NS
RAPID TRAVERSE ....................... 150 IPM
DIGITAL READ OUTS .................... YES
DUAL CONTROLS ........................ YES
COOLANT .............................. YES
MOTOR ................................ 50 HORSEPOWER
FEED MOTOR ........................... 7-1/2 HORSEPOWER
CONTACT US AT:
[email protected]
800-622-4463
CHECK US OUT ON THE WEB:
WWW.YODERMACHINERY.COM
