Weigh feeder local control unit schenck vlg 20100
Weigh feeder
Weigh feeder control is used to control the belt speed of weigh feeder through a variable frequency drive, speed of the belt is measured by the speed encoder, controller measures the speed and then calculate the total feed by multiplying speed amd weight on load cell, so feed rate is compare with the setpoint of weigh feeder given by the ccr operaor, according to differnce in set point and feed back manipulated galue is generated by the controller which is analog signal of 4 to 20 milli ampere to adjust the speed of vfd motor to match setpoint and feedback,
