209 - KENWOOD VT-181 AC mv meter - First test and calibration
Автор: TheHWcave
Загружено: 2026-02-06
Просмотров: 76
Описание:
I got a used VT-181 from eBay because the price was ok and because I had looked at the schematic and noticed an unusual way of range switching, offering the potential to develop an auto-range function in the future - maybe.
#ElectronicsCreators
#VT181
#TheHWcave
#TEST
#CALIBRATION
#vintageelectronics
My video of a similar meter, Levell TM3B: • 168 - "Levell"-Up! Comparing TM3A and TM3B...
You can support the channel by becoming a patron. https://www.patreon.com/user?u=45604138
As a patron you get early access to all my videos as well as exclusive content.
0:00 Fuses
1:28 First test
2:16 Variants
3:15 More tests
3:56 Calibration
5:33 Inside
6:06 Block diagram
7:27 Schematic
9:15 Performance
