How To Repair / Replace a 6.35mm to Mini 3.5mm Headphone Jack (Beyer Dynamic DT100 Lead)
Автор: Savvas Papasavva
Загружено: 2013-01-01
Просмотров: 102391
Описание:
How To Repair / Replace a 6.35mm to Mini 3.5mm Headphone Jack (Beyer Dynamic DT100 Lead)
0:12 Using a voltmeter to check the connection to the jack, making a note of the colours of the wires connected and that the jack to be replaced is designed similarly.
0:38 Carefully take original jack to be replaced off.
1:05 Strip wires.
1:36 Pass components of new jack including heat shrink tubing onto wire before soldering.
1:54 Add small amount of solder to wires.
2:03 Attach new jack.
2:38 Crimp jack to wire.
2:45 Using the voltmeter check connections on jack. (3:20 Follwed by other end of cable.)
3:05 Heat shrink tubing to grip and protect cabling, allow to cool and then screw everything together.
3:20 Double check connection if your cable is as such before plugging in.
