ANT Maschinenhandel UG, Germany presents:
Rietstack IRS 550 Basic Full automatic Die-Cutting machine
Year: 2017
Condition: exzellent
Designed for finishing label and packaging products from roll material (paper, cardboard, IML)
Maximum web width: 550 mm
Maximum mechanical speed: 200 m / min
Roll diameter on unwinding: 750 mm
Spindle diameter on unwinding: 76 mm
Diameter of a roll on winding: 440 mm
Maximum cutting width: 550 mm
Cutting length (rapport of the cutting cylinder) 96-200 Z
Matrix waste winding diameter: 500mm
Maximum productivity in cutting mode with a register of 100 m / min (depending on the material)
Equipment
Material unwinding unit, including 76 mm pneumatic spindle
Roll diameter control system
Automatic stop at the end of the roll
Cardboard smoothing unit (decurler)
Microprocessor control system
Web Edge Alignment Device BST
Servo-driven mesh waste winder
Bookmark sensor (flag tags)
Pressure shaft
Dancer Shaft Adjustment System
Material support plate with antistatic device
Cutting section (servo-drive) prepared for working with standard die cutting tools
Hydraulic pressure regulators in the die cutting section
Vacuum belt
Touch Panel Finishing Machine Control
Winding shaft (servo-driven) with 76 mm pneumatic spindle
Counter with photosensor
Conveyor with stop system
Conveyor drive
Lock discs
Air pump
Dividing belts
Stacker Engine
Stacker Reception Table
Pushers
Transport belts
A table for accepting finished packs of blanks
Scissors slitting device
Front desk and conveyor control panel
Active type anti-static rods
Register sensor
