Automotive Ethernet Testing & Measurement Techniques
Автор: Testforce Systems
Загружено: 2020-03-25
Просмотров: 2797
Описание:
Today’s PAM3 test methods rely on inefficient methods to derive signal quality that don’t provide enough accuracy to be 100% confident in your designs. New methods for advancing PAM3 testing using signal separation provide improved protocol decode, signal quality testing and PAM3 analysis that make your job much easier.
This webinar will cover the effect these new methods have on:
• Visibility of actual data between ECU#1 and ECU#2 without disturbing the cable layout
• Automotive ethernet signal integrity (eye opening, jitter, BER) when operating in full duplex mode
• Using eye diagrams for Open Alliance Signal Quality Test rather than relying on SQI values
• Signal quality during cranking, switching on DC motor, and other auto operations
You will come away with an understanding of how to accelerate your designs and development, while reducing testing costs, and you’ll receive a preview of the new automotive signal separation solution from Tektronix.
