Expert 700 - Stone Saws
Автор: Battipav | Make Your Italian Cut ⚡
Загружено: 2016-06-13
Просмотров: 45762
Описание:
Stone saw ideal for the building sector suitable for cutting bricks, poroton blocks, marble blocks and all the different kind of materials for the building sector.
Equipped with:
Three phases engine 400V 50Hz 5,5Hp/4Kw with thermal and amperometrical protection
Switch with release coil and overheat protection with manual reset
Adjuistable cutting head
Sliding working table
Kit wheels
Adjustable legs
Adjustable goniometer fence
Water recycling pump type S3
Max cutting length: 550 mm
Max cutting depth at 90°: 270 mm
Max cutting dept with 2 RUNS: 340 mm
Water tank capacity (min/max): 21/32,5 liters
Water cooled
Disk Ø700 mm not included.
-----------------------------------------------------------------------------------------------------------
Segatrice ideale per il cantiere edile, adatta al taglio di laterizi, manufatti in poroton, blocchi lapidei e materiali destinati alla costruzione.
Equipaggiata con:
Motore trifase 400V~50Hz 5,5Hp / 4Kw con protezione termica e amperometrica
Interruttore di minima tensione con disgiuntore di corrente a riarmo manuale
Testa di taglio regolabile
Carrello scorrevole e testa di taglio basculante
Kit ruote
Gambe regolabili
Squadra goniometrica regolabile
Pompa ricircolo acqua tipo S3
Lunghezza max di taglio: 550 mm
Profondità max di taglio: 270 mm
Profondità max di taglio in 2 PASSATE: 340 mm
Capacità vasca (min/max): 21/32,5 Lt
Lavora con acqua
Disco Ø700 mm non incluso.
