Minimum volume Oriented bounding Box | Galapagos | Grasshopper 3D
Автор: Ilmar Designs
Загружено: 2019-02-23
Просмотров: 4025
Описание:
In this video I am demonstrating how to generate a minimum volume Oriented Bounding box with Grasshopper components. OBB can be employed to capture randomly oriented 3D object orientation and to align it to the global axes in Rhino work space. It can be extremely useful to align complex geometry, such as 3D scans, free-form objects, groups of objects, etc. A list of utilised native Grasshopper components:
1. Brep parameter
2. BBox
3. Rotate 3D
4.Transformation compound
5. Transform
6. Volume
7. Galapagos
8. Deconstruct Brep
9. List item
10. Area
11. Plane 3Pt
12. Orient
Enjoy!
#grasshopper3D #OBB #Galapagos #AABB #Orient
