Cheap PushPull Power Boost Inverter Modules, Schematics, Details, Testing
Автор: Konstantin Grigoriadis
Загружено: 2024-07-26
Просмотров: 8158
Описание:
This Video is again about a cheap module that I use for it's Transformer only.
It uses a Powerful 500w (or so) EC42/21/20(15) PC40 Ferrite Core, the Transformer is designed for delivering up to 380V from 12V(or 24V) in PushPull Configuration. I intent to use the Transformer for the Modular High Voltage Tube Power Supply design I presented the in a Previous Video. I reverse Engineered it long ago and today I want to share the Design of this little China Inverter Module along with Details on the Schematic.
All-in-One HV Power Supply for Vacuum Tubes #01; Design Concept, Specifications:
• All-in-One HV Power Supply for Vacuum Tube...
Please don’t forget to like and subscribe. Thanks for watching...
!!! Thank you to all my subscribers !!!
If you enjoy my videos, you can help support the channel with a single contribution via PayPal:-
https://www.paypal.com/paypalme/konstgrs
#electronicscreators
#switchmode
#powersupply
#highvoltage
#pushpull
