Prusa 3D Printer Enclosure - Fitting PrusaBox Modular Front - Pi / Screen / Octoprint Octodash

Описание: Prusa Box, 3D printer enclosure for Prusa Mk3. How to fit the modular front panel that includes LCD screen, Raspberry Pi with Octoprint Octodash, switches for LED lighting and extractor fan / temperature control.

Please SHARE, LIKE and SUBSCRIBE to keep informed when new videos are posted.

Next Video - Fitting w1219 Temp Controller / Fan speed control / Noctua fan speed control    • Temperature Controller w1219 for 3D Printe...

If you want more details on the Prusa Box specs, including the modular front STL, please see the manufacturers website
https://www.printer-box.com/?wpam_id=1

Watch the entire Prusa Box series starting with unboxing    • PRUSA BOX - Prusa i3 Printer Enclosure (MK...

The Prusa Box is a highly customisable enclosure, allowing extractor fan, hepa/carbon filters, thermostat, webcam, Raspberry Pi with screens from 3.5" to 7" and much more.

Note that some links may be affiliate links, to help this channel. This does not affect the manufacturers prices.
-----
Useful items:
Screen: Waveshare 5" DSI (as per this video)
UK https://amzn.to/3koYS8w USA https://amzn.to/3yFsPpI
[SETUP link HERE https://www.waveshare.com/wiki/5inch_...]

Screen: Hyperpixel 4" UK https://amzn.to/3zryC3G USA https://amzn.to/3DkjPtN (not tested)

Other screens may fit, but must NOT use a HDMI for connection from screen to Pi, as there is no room. Ideally use a ribbon cable between screen and Pi. Check fitting before purchase.
Pi 3.5" screen bezel is also available for the modular front.

All three screen size bezels are available from https://www.printer-box.com/?wpam_id=1
-----
STL Files
The modular panels are available in the downloads section of https://www.printer-box.com/?wpam_id=1

Enhanced STL versions edited by myself;

End plate with safe shutdown Pi swtich socket designed for 10mm wide push switch: https://www.prusaprinters.org/prints/... (refer    • Raspberry Pi Power Switch Button - Safe Sh...  )

5" Waveshare LCD Bezel with the addition of a hole for a 3mm LED: https://www.prusaprinters.org/prints/... (refer to    • Add a Power LED to your Raspberry Pi Case ...  )

30mm fan guard: https://www.prusaprinters.org/prints/...

If you want to view previous videos, please join the channel and view the range of mods and "how-to's" created so far.

Coming Soon:
Add on modular front for Noctua speed controller inc 30mm fan
Add on modular front for W1219/PWM including 30mm fan
PSU cooling assistant
SUBSCRIBE to get notified of these developments - the STL files will be free.
