116.1c Frequency Modulation (FM) ON15 P41 Q11 | A2 Communication | Cambridge A Level Physics

Описание: How to use info signal to vary FREQUENCY of carrier signal? Try out the simulation below!
00:00 Time domain graphs
03:30 Describing FM
04:27 Example ON15 P41 Q11 #9702w15p41

SIMULATION
Amplitude Modulation (https://www.geogebra.org/m/WAby9sC8)
Frequency Modulation (https://www.geogebra.org/m/ANBK5wfK)

9702/41/O/N/15: A carrier wave is frequency modulated. #A2fmP4 #Lv2
(a) Describe what is meant by frequency modulation.
(b) The sinusoidal carrier wave has a frequency of 750 kHz and an amplitude of 5.0 V. The carrier wave is frequency modulated by a sinusoidal signal of frequency 7.5 kHz and amplitude 1.5 V. The frequency deviation of the carrier wave is 20 kHz V–1.

Determine, for the frequency-modulated carrier wave, (i) the amplitude, (ii) the minimum frequency, (iii) the maximum frequency, (iv) the number of times per second that the frequency changes from its minimum value to its maximum value and then back to the minimum value.
