Here's How to Write G-Code for U Drill Drilling and Rough Boring

Описание: In this video, Marc from ‪@GCodeTutor‬ shows us how to write a sequence of G-Code to both drill and rough bore using a U-Drill.

Marc starts off by writing the G-Code that sets our machine in a safe working state before moving on to the drilling section. When drilling with a U-drill, we write the G-code as we would for a standard point-to-point drilling operation without using cycles. Once the hole has been drilled, we can then offset the U-drill to use it as we would a boring bar.

Marc talks about the calculations we need to do to work out the offset amount to produce a bore with a finishing allowance for a later finish bore operation.

To complete this sequence, we then finish writing the rest of the G-code to return our tool to a safe place, ready for the next tool change.

To learn more about programming with G-Code, head over to https://gcodetutor.com, where Marc has a range of free articles and paid courses to teach you how to program these fantastic machines.

~~~~~~~~~~~~~~~~~~~~~~~~~~~~
