Engine type H series BS-VI - 6 cylinder, CRS with iGen-6 technology
Max power / torque rating 200 HP @ 2400 rpm,
700 Nm @ 1200-2000 rpm
Clutch 380 mm dia - Single dry plate, organic clutch with air
assisted hydraulic booster
Gearbox type 6 speed synchromesh – 3 options /8 speed Synchromesh

Rear axle Fully floating single speed rear axle, RAR: 5.29 / 5.57 /
6.17:1 Optional : Unitized wheel bearings

Front axle Forged I section – Reverse Elliot type, Optional : Unitized
wheel bearings / Anti roll bar

Suspension Front : Semi elliptic multi leaf. Optional : Parabolic
springs Rear : Non-reactive suspension.
Optional : Slipper ended suspension

Chassis frame HSS material with new improved design
Dimensions : 275 X 75 X 7/8mm bolted construction

Brakes Full air dual line brakes with ABS and auto exhaust brake

Fuel tank On LH side (RH side only on POL variant) -
Aluminized steel cross linked polymer -
Capacity : 220L / 300L / 375L
Optional : Additional tank on RH side

Ad blue tank 48 Lts capacity on RH side

Max speed 80 kmph

Electricals 24V-120 AH (150AH for AC Models)

Tyres 295/90R20 – 16 PR

Cabin G – Economy Cowl, M -Economy cabin
U -Value cabin and N - Premium cabin
AC option on U/N variants

Vehicle configuration Cowl & chassis / Cabin & chassis / FSD / HSD

Chassis weight (Laden) kgs FAW – 7000 ; RAW - 21000 GVW - 28000

Major dimensions
Load body size (ft) 20 | 22 | 24 | 26 | 28 | 30 | 32
Wheelbase (mm) 4700 | 5050 | 5450 | 5750 | 6000 | 6300 | 6600
Overall length (mm) 8510 | 9110 | 9710 | 10360 | 10960 | 11560 | 11960
Turning circle dia (m) 15.7 | 17.0 | 18.23 | 19.7 | 20.7 | 21.62 | 22.7
Overall width (mm) 2570
Overall height (mm) M – 3145 | U – 3165 | N - 3110
