Whelen Avenger TRIO Dual Linear Super-LED Dash/Deck Light
Автор: SIRENNET
Загружено: 2014-12-08
Просмотров: 20325
Описание:
http://sirennet.com/whavnt2.html The Whelen Avenger TRIO Dual Linear Super-LED Dash/Deck Light incorporates six Super-LEDs for each of the three colors in each warning light module. The TRIO warning lights are installed in a black polycarbonate housing with a clear non-optic linear lens. The hard coated lens provides extended life/luster protection against UV and chemical stresses. The conformal coated PC boards and lens/reflector assemblies provide additional protection against environmental elements. These solid state warning lights are vibration resistant. The self-contained flashing lights have 55 Scan-Lock flash patterns including steady burn and ten mode operations including white steady override options. The cigar plug contains two On/Off switches: 1 for the White Steady Override and the other for Color Flashing mode. The main housing contains two built-in switches: 1 for Scan-Lock flash pattern switching, the other for color mode operations control. The AVNT2 includes a 10 foot straight cord cigar plug with an 8 AMP fuse. The Avenger installation kit includes a metalized polycarbonate windshield shroud and an adjustable universal swivel/bail bracket assembly with three suction cups. The tri-color warning light is covered by a five year factory warranty.
Available color sets:
AVNT2RBW - Dual, Each Lighthead Red/Blue/White, with White Steady Override
AVNT2RBA - Dual, Each Lighthead Red/Blue/Amber, with Amber Steady Override
AVNT2RAW - Dual, Each Lighthead Red/Amber/White, with White Steady Override
AVNT2BAW - Dual, Each Lighthead Blue/Amber/White, with White Steady Override
Features:
10 - Color switching modes.
55 - ScanLock Flash Patterns including Phase 1, Phase 2 and Steady-Burn.
Six Super-LEDs for each of the three colors in each warning light module.
Hard coated, clear non-optic linear lens for extended life/luster protection against UV and chemical stresses.
Black polycarbonate housing.
Black polycarbonate windshield shroud.
Adjustable universal swivel/bail bracket assembly with three suction cups.
Cigar plug contains two switches for On/Off and Scan-Lock flash pattern/mode operations control.
10 foot straight cord cigar plug with an 8 AMP fuse.
Specifications:
Voltage: 12 VDC
Size: 5.00": H x 9.75": W x 5.48": D.
Amp Draw Each Light Module: 0.80 Amps Warning, 0.80 Amps Steady White override.
Whelen Five Year Warranty
