Scissor Lift Mechanism Travel Control in Fusion 360 | Slots, Motion Limits & Interference
Автор: Fusion 360 - How Would I Do It
Загружено: 2026-02-03
Просмотров: 263
Описание:
In this tutorial, we show how to control how low and how high a scissor lift mechanism can move in Fusion 360. Starting from an existing assembly, we extend the mechanism’s range of motion by editing slot dimensions and positions, adjusting motion limits for pin-slot and slider joints, and resolving interference between profiles.
We use Section Analysis to identify conflict points and refine the geometry so the mechanism can travel smoothly over a longer distance.
This video is part of a dedicated playlist focused on scissor lift mechanism design, motion control, and mechanical analysis in Fusion 360.
⏱️ Chapters
0:00 Introduction – limited travel problem
0:25 Editing slot dimensions and positions for longer motion
1:49 Adjusting motion limits for the pin-slot joint
3:19 Solving profile interference and conflict points
5:46 Editing motion limits for the slider joint
