Shimano Di2 EW SD50 wire physical measurements
Автор: Steve Rabson
Загружено: 2021-09-02
Просмотров: 551
Описание:
I needed to splice some Di2 wires together in a bundle in order to save money by eliminating the need for the Di2 junction box. I took these measurements to help find a suitable twin conductor cable for splicing in. Thought it may be useful for others out there, so here it is. No audio. Just a video of my measurements, but hopefully it is still of use.
13 September 2021. Further info on splicing wire. I couldn't find an identical cable at a decent price. The closest I have found is: DEF STAN 7-1-2A PVC/PVC 0.055mm Black MFG P/N: MP002312. Manufactured by Multicomp Pro and available from CPC. Order code: 3372774. It is two core jacketed cable with blue and red sleeved cores. Each core has 7 strands of TC wire. There is a plastic wrap around the cores and a string that runs through the cable as a strain relief, something the Shimano cable doesn't have. I bought it as a 25m reel for about £4 plus £6 postage.
