Onshape BEGINNERS guide / Step-by-step tutorial

Описание: #onshape #revolve #parts #holes #slots #counterbore #pattern #skip #instances
In today’s #onshape step by step tutorial, certified EXPERT #TooTallToby takes though the process of creating a REVOLVED part. We’ll learn how to apply some fundamental Onshape skills including:
Planning to go from 2D to 3D
Using Doubled Dimensions for #turned #parts
Revolving a feature
Creating #slot features
Setting a starting offset for an EXTRUDE
Using the #hole command to create #counterbores in Onshape
Creating a circular pattern and using

Original PRACTICE MODELS challenge:    • 2D Drawing to 3D CAD - PRACTICE MODEL- Exe...

More practice models examples www.TooTallToby.com/practice

Get 6 months of Onshape Professional for Free
Onshape.pro/tootalltoby

0:00 INTRO
0:45 Planning to go from 2D to 3D CAD
2:37 Create our first sketch using Diameter Dimensions for a revolved feature
5:03 Assign Custom Materials in Onshape
5:39 Cut Revolve in Onshape
6:43 Renaming Features in Onshape
7:13 Using NORMAL TO view in Onshape
9:09 Creating SLOT geometry in Onshape
9:58 Using STARTING OFFSET for extrudes
10:28 Creating Holes and Counterbores in Onshape
11:25 Circular Patterns in Onshape with SKIP INSTANCES
12:20 Calculate Mass in Onshape
