How to Change the PMD Series Display High Alarm Setpoint

Описание: The Sensor Connection instructional video for the "SuperLite" PMD Series LED digital display Pyrometer. This video reviews how to change the High Temperature Alarm Setpoint.

Product: PMD1XT Digital Indicator
Topic: How to change the PMD1XT Digital Indicator High Temperature Alarm Set-Point Value

Once the indicator is powered on we are ready to begin the procedure.
Begin by pressing the SET key once (x1)
Next, using the up & right arrow keys, enter the programming code 0001
Once the code is in the display then press the SET key (x1)
The indicator is now in the programming mode
The display will read “AH1”
Press the set key once (1x). Using the up & right arrow keys enter the temperature value at which you want the alarm to activate. For this example, we will choose 500 degrees.
Once the chosen High Alarm set-point activate value is in the display press the SET key once (x1) to save the value in the microprocessor’s memory.
Next, press the UP ARROW KEY once (1x). The display will read “AL1”.
Press the set key once (1x). Using the up & right arrow keys to enter the temperature value at which you want the alarm to deactivate. For this example, we will choose 400 degrees.
Once the chosen High Alarm set-point deactivate value is in the display press the SET key once (x1) to save the value in the microprocessor’s memory.
Press the UP arrow three times (3x) until END is in the display window. Then press the SET key once (x1) to exit the programming mode.
The indicator’s High Alarm now activates if the measured temperature value is greater than 500 degrees
(2 SECOND PAUSE)
& deactivates if the measured temperature value is less than 400 degrees.
For more information please visit our website thesensorconnection.com to download a copy of the PMD1XT Digital Indicator user’s manual & quick start guide.
