Simple Product Counting Conveyor Using Solidworks Proximity Sensor and Mechanical Counter
Автор: Solidworks Fun
Загружено: 2021-05-12
Просмотров: 14177
Описание:
This is a simple product counting conveyor design, it consists of a Mechanical Counter and Solidworks Proximity Sensor.
The Proximity Sensor Senses the position of the product (here a simple box) on the conveyor and then triggers the motion of Mechanical Counter to indicate the number of products passed through it.
This conveyor shows one of the application of a proximity sensor. For the Counting Mechanism, usually digital counters are used but to in this tutorial We have used a Mechanical Counter.
1. Mechanical Counter Mechanism Design Assembly and Motion Study in Solidworks
• Mechanical Counter Mechanism Design Assemb...
Hope You like it.
Do Share your opinion in the comments.
Thanks for Watching.
Do like subscribe and share.
Stay connected for such tutorials.
