AC Type 2 Surge Protective Device SPD assembling

Описание: AC Class C, Type 2 Surge Protective Device SPD assembling

https://lsp.global/type-2-spd/

Type 2 Surge Protector Device SPD SLP40 series are generally installed in sub-distribution or machine control cabinets.

Thanks to unique trigger release, effectively solve the isolation and extinguishing arc.

00:00 How to assemble a Type 2 SPD?
00:04 Place the circuit board into the base of the surge protector.
00:08 Insert the trigger spring and transmission rod.
00:13 Insert the metal parts and internal busbars.
00:18 Insert into the terminal block.
00:23 Close the top and bottom covers of the base.
00:32 Installing din-rail buckle.
00:38 Base assembly completed.
00:44 Insert the built-in spring.
00:48 Insert the arc extinguishing partition plate.
00:51 Insert the metal fixture used for fixation.
00:55 Insert metal electrode.
01:02 Selecting the appropriate MOV (Metal Oxide Varistor).
01:06 Insert the MOV into the inner shell.
01:10 Place the semi-finished product into the welding fixture.
01:24 Choose the correct low-temperature solder for welding.
01:33 Remove the semi-finished product from the welding fixture and check the MOV again.
01:42 Laser print on the surge protective device.
01:45 The outer shell closes with the inner shell.
01:56 Insert the pluggable module into the base.
02:03 Recheck the finished product.
02:07 Place the SPD, instruction manual, and floating switch terminal into the paper box.
02:28 Pack the product in double corrugated boxes.
----------------------------------------------------------------------------------------------------------------------------------------------------
Since 2010, LSP has been dedicated to designing and manufacturing surge protective devices protecting installations from transient overvoltages that result from switching events and lightning strikes.
----------------------------------------------------------------------------------------------------------------------------------------------------
