Mantap Antena Wirelless jarak 50km sinyal full dengan Airfiber 5X

Описание: The airFiber 5X is designed for long-range point-to-point backhaul links. It features the highest TDD throughput available on the market. Building upon the proven design of the airMax Rocket system, airFiber 5X allows customizable airFiber backhaul links or upgrade existing Rocket PtP links. The first airFiber 5X model is the AF-5X model for use in the 5GHz frequency. It features industry leading 10.6bps/Hz spectral efficiency, covering the entire 5GHz spectrum with one radio.

Optimized Performance
Ubiquiti's INVICTUS custom silicon and proprietary radio architecture are designed specifically for long distance outdoor applications. The AF-5X features 10.6bps/Hz spectral efficiency, line rate data packet processing for up to 500+Mbps of real data throughput, and innovative xtreme Range Technology (xRT) for up to 200+km in range.

GPS Synchronization
Precise GPS frame synchronization frees the AF-5X from interference for superior co-location capability. GPS enables the concurrency of TX and RX frames so you can co-locate the AF-5X radios and enhance the overall performance of your backhaul links.

Product Specifications
Operating Frequency: 5150-5925MHz
Channel Bandwidth: 1MHz
Maximum Throughput: 500+Mbps
Maximum Range: 200+km
Encryption: 128-bit AES
Operating System: airOS F
Conducted TX Power: 26dBm
Frequency Accuracy:
RF Connectors: 2 x RP-SMA weatherproof, 1 x SMA weatherproof
GPS Antenna: external, magnetic base
Power Supply: 24V, 1A PoE Gigabit adapter
Mounting: airFiber X Mount (Rocket Mount Compatible)
Operating Temperature: -40 to 55 C (-40 to 131 F)
Data Port: 1 x 10/100/1000 Ethernet Port
Management Port: 1 x (1) 10/100 Ethernet Port
Dimensions: 224 x 82 x 48 mm (8.82 x 3.23 x 1.89in)

terima kasih sudah menonton video kami ini untuk instalasi antena airfiber dapat menghubungi :
CV. LINTAS MEDIA INTEGRASI
HP/WA : 08125725167 Email :[email protected]
