Tutorial: Make and edit scientific svg figures using INKSCAPE and MATLAB in 12 mins
Автор: engrSMART
Загружено: 2025-04-04
Просмотров: 838
Описание:
Learn how to create a scientific figure (vector image, svg) using INKSCAPE with MATLAB step-by-step! Perfect for beginners who want to create and edit scientific vector images.
In this Lab tutorial, you'll learn:
Basic functions and settings of an oscilloscope
Brief theory for finding the time constant
Finding the time constant using an oscilloscope
Tips for analyzing and troubleshooting
00:00 Introduction
00:14 Create figure using MATLAB and save it as *.svg file
01:52 Basics (zoom in, out, group, ungroup) of INKSCAPE commands
03:07 Edit axes (type, align, rotate)
06:41 Edit curves (color, duplicate, line spec)
08:51 Save as *.svg
09:13 Save as *.emf for Microsoft products, such as MS Word
10:27 Export as *.png (raster image)
MATLAB BASICS: Import (LabVIEW .lvm file) and plot data:
• MATLAB TIPs: Import (LabVIEW .lvm file) an...
#inkscape #inkscapetutorial #svg #MATLAB #matlabtutorial
