TANCO TRIPLE MOWER

Описание: Tanco triple mower M9(29ft) & M10(32ft)
The AUTOCUT's trailed system distributes the weight between the tractor and mower wheels, this greatly reduces stresses on the tractor and mower.
The improved weight distribution and flotation of the rear mower beds results in a reduced horsepower requirement and fuel consumption. The result is a 8.9m cutting widths being achieved with 180HP+ tractor.
33.5 inch of Vertical Travel
The advanced AUTOCUT chassis allows simultaneous horizontal and vertical movement independent of the tractor's front linkage. 850mm of vertical travel ensures the front mower follows the most severe hollows and throughs.
The front mower achieves 16° of transverse movement independent of the tractor linkage, giving the M3 exceptional movement in undulating ground.

The 56 Series Heavy Duty COMER cutter bar is formed from a single piece of stamped metal. 25mm gear drive train and shear hub technology is used throughout with 4.2 ltrs [M3] 4.8 ltrs [M9] & 5.5 ltrs [M10] oil capacity. . Reversible Quick-Attach blades rotate 360 degrees in their holders, the blades can rotate freely in the event of contact with an obstruction, meaning blades can be used on the reverse side.
Shear Hub Technology
Each module is protected by Shear Hub Technology. In the event of a collision, a pre- defined break-point within the hub, shears. The damaged mower disc is disengaged from the drive train with an axial bolt holding the disc in place. This avoids the load spike being transferred along the drive train to other modules significantly reducing damage.
Active Steering
The AUTOCUT's 'Active Steering' feature allows for a fast and slow steering response depending on the requirement. A steering angle of up to 40° allows the mower beds to move directly to the next row. While during road use, when the mower beds are folded, the slower response ensures the rear mowers follow the line of the tractor, allowing the driver to focus on the road ahead.
COMER Gearboxes & PTOs
A direct drive transmission system gives straight drivelines resulting in little to no power loss to the cutter bed. . The COMER VP PTO drive shafts improves movement during use and feature an external grease point with seals allowing lubrication without separating the shafts.
