WLAN IEEE 802.11be: Transmitter Measurement with PathWave 89600 VSA

Описание: Transmitter Measurements with Keysight PathWave Vector Signal Analysis Software (89600 VSA)
IEEE 802.11be/Wi-Fi 7 is the next generation WLAN building on 802.11ax/Wi-Fi 6 but it increases the throughput at lease of 30 Gbps and supports the frequency operation in 2.4 GHz, 5 GHz and 6 GHz bands. Although this new standard is still in the draft phase and is targeted completion in 2024, some chipsets, modules and transmitter customers are already working on research and testing of their devices. In this video, we will introduce you to the new IEEE 802.11be standards and new technologies such as 320 MHz Bandwidth, 4096 QAM, Enhanced OFDMA, and more spatial streams. The video presents you with a procedure on how to use Keysight Signal Studio software to generate the 802.11be signals and then use the PathWave Vector Signal Analysis software (89600 VSA) to demodulate the 802.11be signals. Constellation, Data Burst Info, Multi-user Info, OFDM SIG Info, and metric results including EVM and IQ errors can be shown in the demodulation analysis software. Furthermore, the spectrum emission analysis (SEM) measurement is also mentioned in this video with the new PowerSuite measurement supported by the 896000 VSA software.
