IMS 4 7 Gallon Tank Install - Yamaha WR250R
Автор: Southwest Trails and Wheels
Загружено: 2022-04-08
Просмотров: 3193
Описание:
The IMS 4.7 gallon tank should give my WR250R over 250 miles of range to help conquer the NMBDR and the COBDR this year. Amazon link to the correct fuel tank below.
IMS 4.7 gallon tank for the WR250R: https://amzn.to/3xyBgs5
Steps I followed to install:
00:03 Remove front shrouds and seat
00:37 Unbolt and drain tank
00:56 Disconnect vent hose, power cable, and fuel line
01:21 On CA models connect long vent hose to plastic roll over valve
01:53 Note fuel spigot orientation, remove pump, replace pump O-ring
02:30 Locate lift pump outlet house and cable-tie to stock pump
03:04 Install fuel pump in tank with spigot in original orientation
03:42 Transfer stock front and back mounting brackets onto IMS tank
04:27 Locate vacuum line from throttle body per instructions
05:05 Place IMS tank onto the bike to reconnect fuel line and power cable
05:36 Connect vacuum line from tee or directly from throttle body to back of tank
05:56 Bolt tank to frame using stock bolts
06:21 Transfer seat hook to IMS tank & replace seat
06:59 Tighten front shroud bolts
07:15 Clean tank surface, admire your work, refill tank, check for leaks
