Controlling motion of curved slider 3
Автор: thang010146
Загружено: 2025-07-22
Просмотров: 7063
Описание:
Input: red crank rotating regularly.
Output: pink slider.
Here the mechanism shown at:
• Mechanism for drawing circle 3
is applied therefore, the force acting on the curved runway is negligible.
A four-bar linkage (green, brown and red bars) is used to convert the continuous rotation into the reciprocating rotation of the red bar.
To enlarge the output angle, instead of the for-bar linkage, use other mechanisms such as:
• Bevel gears for angular reciprocation
STEP files of this video:
https://www.mediafire.com/file/xp8qaf...
Inventor files of this video:
https://www.mediafire.com/file/kk9zo7...
