50 Series Sprayer

Описание: Get an in-depth look at Demco's 50 Series Big Wheel Sprayers with this virtual demonstration video!
----------------------------
Demco 850, 1050, & 1250 50 Series Big Wheel Sprayers have a proven design loaded with features with your convenience and efficiency in mind, built for your farming operation. Our exclusive tank design allows for unmatched agitation and drainage. Our short trailer design helps reduce crop damage, and our front folding hydraulic booms are built to perform! The 50 Series Sprayers work effectively and are cost effective. These field sprayers are a fraction of the cost of a self-propelled sprayer with less maintenance and more capacity.
----------------------------
Features: The polyethylene tanks have a 16" flip-top lid and 2 high volume jet agitators. Its molded-in trough drains spills to rear of sprayer. The 100 gallon 2 stage sump provides optimum tank drainage and decreases sloshing. Has an external liquid site gauge, 120 gallon rear mounted rinse tank, and a 2 1⁄2 gallon hand wash tank. The ¼" steel-formed frame with 30" ground clearance, reducing crop damage. The fold-away ladder provides easy access to the large work platform, for added safety when filling tank. Has one of the shortest “hitch pin to axle” lengths in the industry - 140"! Includes a large storage compartment conveniently located for storing extra nozzles, clamps, etc. The single tube hitch frame allows for improved turning. Pump and plumbing are center mounted allowing for shorter hoses and improved pump priming. 50 mesh main filter and 80 mesh feeder line filters prevent tip plugging. Has centrally located controls for convenient valve operation. Has 2" quick couplers for bottom filling tanks. The hydraulic front fold booms feature a nitrogen charged accumulator system combined with leveling linkage and shock absorbers to soften the ride. Live hydraulic control block requires only one set of remote outlets to perform all boom functions. The hydraulic pendant/block can be used with open or closed center tractor hydraulic systems. Booms feature independent wing fold, hydraulic height adjust, wing leveling and outer wing breakaway and are available with 3/4" high volume plumbing and TeeJet® diaphragm check nozzles spaced at 20". All booms have stainless steel boom and hose clamps. Light system consists of flasher/turn signal and taillights for added road safety. Optional accessories include a 7 gallon chemical eductor and a 33 gallon foam marker.
----------------------------
Learn More: https://www.demco-products.com/agricu...
