dolphicam2 cfrp impact damage demo
Автор: dolphitech
Загружено: 2020-04-08
Просмотров: 519
Описание:
How much impact can CFRP resist? Well as we like to say, how long is a rope? It depends. But here you can see what happens when we drop 1 kilo from different heights.
dolphicam2 is ultrasound imaging platform for NDT, for inspection of metals, CFRP, GFRP, glare, rexolite and multi-materials.
The dolphicam2 platform consists of a TRM, black box and Toughpad (or PC).
TRM frequency range from 0,5 to 11 MHz. With 128 x 128 transducer electrodes, in total 16384 transducer elements producing A-, B-, and C-scans in Amplitude and Time of flight. Analysing with high amounts of data gives live 2D and 3D images. Large area stitching.
