Levelling Up Your KiCad Skills
Автор: Steph Baker
Загружено: 2025-11-04
Просмотров: 156
Описание:
This video covers a range of new PCB design skills in KiCad, including designing custom symbols and footprints, multi-layer routing, using a secondary layer as a ground (or power) plane, and using the silkscreen. Also some bonus mini-skills like using net labels for prettier schematics and editing all traces/vias using selection filters.
00:00 Introduction & Example 1 Overview
00:45 Designing a custom schematic symbol
06:41 Adding our custom symbol to a schematic
07:19 Using net labels to simplify your schematic
08:43 Designing a custom footprint
15:22 Assigning the custom footprint to a symbol
15:50 Laying out the PCB with the custom footprint (+ tips for assignment components)
18:50 Predefining track widths and via sizes
19:40 Two-layer routing'
23:22 Modifying all components of a particular type using selection filters
25:30 Adding text to the silkscreen
27:38 Example 2 Overview
28:40 Using an entire layer as a ground or power plane
31:44 Silkscreening a more complex board
