Aciduino - DIY 2 tracks TB 303 step sequencer clone and midi controller

Описание: Aciduino is a cheap and easy to make 2 tracks, 14 patterns, 303 step sequencer clone with generative harmonic engine for harmonized lines, midi controller and midi clock.

Common prices on stores for:
Components: U$ 7.78
Arduino Nano: U$ 19.50
Breadboard + Wirekit: U$ 14.79

BOM list ready to order on mouser.com
https://www.mouser.com/ProjectManager...

You can download the code, manual and protoboard schematic at: https://github.com/midilab/aciduino

Official page:
http://midilab.co/aciduino/

[BOM List]

1x arduino nano
1x solderless breadboard protoboard 830 tie points 2 busess
1x solderless breadboard jumper cable wire kit box
6x 220ohms resistors
6x 6mm taticle switch
6x 3mm diffused leds
4x 10k linear potentiometers

[MIDI connection]

Add more two 220ohms resistors to you boom list and choose one of thoses above methods as main midi conection.

1x 5 pins DIN female connector (standard MIDI connector) + sto protoboard - you need solder skills here.
1x midi cable. Cut it in a half and connect it directly to protoboard - its a good idea to soldering the wire tip before make the connections.

[USB Connection]

Open config.h and set MIDI_MODE to 1.
Download and install a serial-to-midi converter like http://projectgus.github.io/hairless-...
Open your favorite DAW, configure MIDI port to get signal from serial-to-midi converter and just go acidulize with your preferred acid synth plugin. Depends on your operational system you may need a additional MIDI virtual port driver installed.
