BLTouch on SKR Mini – Install Guide

Описание: Auto bed leveling is an excellent upgrade to any 3d printer. In this video, I go over how to install and setup the BLTOUCH auto bed leveling kit on a 3d printer with an SKR Mini mainboard. I walk you through all parts of the process, including installing the hardware, modifying and applying the firmware, and making the necessary changes in Cura to allow it to run at the start of each print.

If you have any questions on the content covered in this video, feel free to leave a comment below with them. I try to reply to all commented within 48 hours.

Cura Profiles: https://3dprintscape.com/cura-profiles
Written Instructions: https://3dprintscape.com/bltouch-on-s...

Referenced Links
Recommended Hardware
Ender 3 Pro on Amazon: https://geni.us/vIAIx
Ender 3 V2 on Amazon: https://geni.us/ur8YHM
HATCHBOX Filament on Amazon: https://geni.us/BJx0Gdj
SKR Mini E3 V2.0 on Amazon: https://geni.us/A9oe
SKR Mini E3 V2.0 + Touch Screen on Amazon: https://geni.us/tO4H
BLTOUCH on Amazon: https://geni.us/AD6M

Firmware
BIGTREETECH: https://github.com/bigtreetech/BIGTRE...
Marlin: https://marlinfw.org/meta/download/

Videos
How to Compile Custom Firmware for SKR Mini:    • How to Compile Custom Firmware for SKR Mini
Z-Offset Wizard Overview:    • Z-Offset Wizard Overview

Other Changes
Platformio.ini Change: default_envs = STM32F103RC_btt_512K

Cura Change: Add the G29 command to the startup g-code section of your machine profile, it should look like this.
; Ender 3 Custom Start G-code
G92 E0 ; Reset Extruder
G28 ; Home all axes
G29 ; BLTouch
G1 Z2.0 F3000 ; Move Z Axis up little to prevent scratching of Heat Bed
..
