IEC 60870-5-104 RTU IED Server Simulator With VTScada HMI

Описание: In this Simulating IEC 104 Monitoring and Command points with VTScada.

Simulate Complete IEC104 RTU Outstation Server

IEC 60870-5-104 Protocol Standard - Monitoring Information


ASDU Read Type Type Identification Type Identifier
SINGLEPOINT - M_SP_TA, M_SP_TB
SINGLEPOINTNOTIME - M_SP_NA, M_PS_NA,
DOUBLEPOINT - M_DP_TA, M_EP_TA, M_DP_TB, M_EP_TD
DOUBLEPOINTNOTIME - M_DP_NA
STEPPOSITION-M_ST_TA, M_ST_TB
STEPPOSITIONNOTIME - M_ST_NA
BITSTRING - M_BO_TA, M_BO_TB
BITSTRINGNOTIME - M_BO_NA
NORMALIZED - M_ME_TA, M_ME_ND, M_ME_TD
NORMALIZEDNOTIME - M_ME_NA
SCALED - M_ME_TB, M_ME_TE
SCALEDNOTIME - M_ME_NB
FLOAT - M_ME_TC, M_ME_TF
FLOATNOTIME - M_ME_NC
INTEGRATED - M_IT_TA, M_IT_TB
INTEGRATEDNOTIME - M_IT_NA




IEC 60870-5-104 Protocol Standard - Command ASDU


ASDU Read Type Type Identification Type Identifier
SINGLECOMMAND- 58 - C_SC_TA
DOUBLECOMMAND - 59 - C_DC_TA
REGSTEPCOMMAND - 60 - C_RC_TA
NORMALISEDCOMMAND - 61 -C_SE_TA
SCALEDCOMMAND - 62 - C_SE_TB
FLOATCOMMAND - 63 - C_SE_TC
BITSTRINGCOMMAND - 64 - C_BO_TA




Download Free Evaluation Kit - IEC 60870-5-104 Protocol Development Bundle
IEC 60870-5-104 Protocol - https://www.freyrscada.com/iec-60870-...


In the Development Bundle, We included IEC 104 Server Client Simulator, Windows and Linux SDK, C# projects, Doxygen documentation and Raspberry Pi, BeagleBone Demo library.


IEC 104 RTU Server IED Simulator - https://www.freyrscada.com/iec-60870-...
IEC 104 protocol client master Simulator - https://www.freyrscada.com/iec-60870-...
IEC 104 Windows Software Development Kit(SDK) - c, c++ c# .net - https://www.freyrscada.com/iec-60870-...
IEC 104 Linux Software Development Kit(SDK) - c, c++ , arm - https://www.freyrscada.com/iec-60870-...
IEC 104 Source Code Library (SCL) - c, c++ c# .net - https://www.freyrscada.com/iec-60870-...


Licensing
Perpetual
One-time payment, royalty-free
Unlimited production volume
Neither license manager nor dongle required


Source Code License model:
In this License model, we deliver complete source code of the protocol implementation according to the customer specified operating system (Windows, Linux, QNX...).
Customer may embed the library into unlimited copies of multiple end-use products for worldwide manufacturing, branding and distribution. Original equipment manufacturers choose this model. They usually have multiple products in their pipeline.


Compiled Library License model:
In this License model, we deliver Dynamic/ Static compiled library (DLL / Lib) of the protocol implementation according to the customer specified operating system (Windows, Linux, QNX...).
Customer may embed the library into unlimited copies of multiple end-use products for worldwide manufacturing, branding and distribution. Original equipment manufacturers choose this model. They usually have multiple products in their pipeline.


Simulator License model:
In this License model, we deliver Simulator Installer for Windows Operating System.
The Customer can use the software company wide. Customer can install the software in many systems. There is no restriction like Hardware key (Dongle) and software key.


Library features:
Our Protocol source code supports different operating system (Windows, Linux, PowerPC, QNX). All of our protocol implemented in ANSI-Standard C Source Code.


We are offering Source code license according to target platform (operating system).


Written in ANSI-Standard C Source Code, under a strict corporate coding standard, and supports C++, C# (.NET)
Can be used with or without a Real Time Operating System (RTOS).
Transparent licensing scheme - No hidden costs, No deferred payments.
High performance, robust and scalable architecture
Provides a simple method for systems Integrators and OEMs to utilize standard tools to implement their systems
Our stacks are fully compliant with "POSIX" and tested in ubuntu, feroda, Debian, QNX, Linux Embedded OS and Various Cross compiler tool chains.
Our all protocol stack supports "POSIX compliant operating system"
Context-based event-driven model
Multiple Server and Client Simulation
In a Single Server(link) simulate Multiple Stations (Common Address)
Supports Background Scan, Cyclic Data Transmission, Double Transmission, Redundancy and File transfer.
Communication with redundant control systems and interruption-free switch over between redundant systems
Supports "Select-Before-Operate" and "Direct-Execute" command execution modes
In IEC 60870-5-104 Client Side, Data Mode and Test mode connection type available.
Source Code Library allows a fast and cost efficient implementation
APIs are designed to be very easy to use and flexible
