How to build a Farmhouse King Bed with sliding barn doors

Описание: Farmhouse king size bed with sliding doors and drawers

This bed was mattress only. If using a box springs, you will need to raise the headboard face 10" thus making the barn doors smaller as seen in the thumbnail picture. Also, using box springs you can space out the middle lattes to 12" instead of 10 for the mattress only.

Post legs: 4x4s cut @ 6’ and 21 ¾” X 2 each
Side Lattes: 2x10s cut @ 78” X 2
Post leg latte supports: 2x4s cut @ 10” X 4

Headboard back: 1x10s cut @ 89.5” X 5
Headboard shelves: 1x4s cut @ 82.5” X 2
Headboard face: 1x4s cut @ 89.5”, 52”, 82.5” (2), 32.5” (2)
Headboard doors: 21.5” X 34” X 2 doors

Footboard face: 1x3s cut @ 82.5” (2), 15 ¾”
Drawer face: 39” X 15 ¼” X 2
Drawer guts
Back guts: 1x3 cut @ 82.5”, 3 feet cut at 3” tall. Width doesn’t matter
Side guts: 1x10 cut @ 16.5” X 2 (must sit back 1.5” from the front)
Middle guts: 1x3s cut @ 18” X 2
Drawer side: 14 ¼” X 16” X 2 per side
Drawer base: 36 3/8ish (measure)
Drawer front and back: 36 3/8” x 13” X 2 per side
Measure out the trim and follow the same steps as the doors.
Lattes:
Sides: 2x4s cut @ 60” X 2
Middle: 2x4s cut @ 79 ¼” X 7
Spaced out 10" on center
Minwax classic grey stain
Brush
Kreg pocket hole machine, 1 ¼” screws, 2 ½” screws
Torx screws: 1 ¼”, 2”, 3”
