How to Install Game / Display ROM & PinSound soundcard in a Pinball Machine. Awesome upgrades!
Автор: RETROCENGO
Загружено: 2024-10-31
Просмотров: 368
Описание:
Direct link to PinSound:
https://www.pinsound.org/
LW3 ROM/Sound upgrade: https://www.pinsound.org/machine/leth...
Compatibility list
PinSound NEO and PinSound PLUS are replacement sound boards for the following original references:
Data East Rev3 : 520-5050-0X / 520-5077-00 / 520-5126-02
System 11-C Sound Board : D-11581
WPC pre-DCS Sound Board : A-12738
WPC DCS Sound Board : A-16917
WPC-95 AV Board (with or without original AV Board) : A-20516-50041
SEGA / STERN Whitestar (CPU section must be working): 520-5136-00 / 520-5137-01
STERN Whitestar (CPU section must be working): 520-5300-00
#new #retrogaming #retrocore #2024 #pinball #sega #music #gaming #dataeast #arcade #how #howto #upgrade #instagram #installation #mod
@pinsound
Lifetime warranty
Every PinSound product is designed to offer a high and long-lasting quality. Our PinSound sound boards have been designed and manufactured with the best care to be incredibly resistant and reliable.
PinSound PLUS is covered by a product lifetime warranty! As long as this product is manufactured, it will be replaced if anything happens due to materials or manufacturing defects. This warranty doesn’t cover misuse or neglect of the product.
Specification:
plug and play pinball machine sound board
auto-detection & auto-configuration system
play with original or custom sounds
up to 7 simultaneous tracks
multiple different sound packages on the same flash drive
switch sound package on-the-fly
up to 48000Hz sound CD quality
3.5 mm jack output (PLUS)
4 extension ports (shaker and future accessories)
smart self-diagnosis status LED
digital dust-resistant RGB backlit potentiometers (PLUS)
hardware protection
user friendly connectors identification
mis-insertion preventing mechanism
overload / overcurrent / overvoltage resettable protection
weak power supply detection
designed with love and passion in France
premium noise isolation
high efficiency 2.1 stereo class-D amplifiers
digital gain controlled pre-amplifiers
audio digital-to-analog (DAC) channels 92dB SNR
4 bands digital tone control equalizer (PLUS)
sub booster control
digitalized analog door volume potentiometer inputs
dedicated PinSound Headphones Station connector
dedicated stereo line-out RCA gold-plated connectors (PLUS)
High quality electronic components
Great care was taken while designing the PinSound NEO and PinSound PLUS. To guarantee high quality audio performance in a single universal integrated board, each electronic components has been selected and qualified.
Cypress embedded system engine
NXP audio amplifiers
Texas Instrument pre-amplifiers
ARM processor
Sandisk memory
DATA-EAST Power Booster:
https://www.pinsound.org/shop/en/41-d...
