Maiden Flight RC 3D Printed ICON A5 - Planeprint

Описание: I will take the 3D Printed Icon A5 out for a maiden flight. I had a problem with the motor and propeller setup I used. I will show how I fixed the problem and take it out for another flight.

Thank you so much for watching!

If you like videos like this, consider buying me a coffee, it really supports me: https://www.buymeacoffee.com/troymcmi...

See what else I am working on:   / troymcmillan_rc
https://www.tiktok.com/@troymcmillan_...
#3Dprinted,#RCairplane, #ItFlies

Thank you so much to https://www.planeprint.com for sponsoring this build!

How to Print Thin Wall:    • How to Print Thin Wall - Planeprint | Big ...

Products Mentioned
ICONA5 STL Files: https://www.planeprint.com/product-pa...

JGAurora A5S 3D Printer: https://amzn.to/3hn5cdN
JGMAKER MAGIC Printer: https://amzn.to/3nmonb6
White PLA: https://amzn.to/3ghcHl1
Black PLA: https://amzn.to/30E4YIT
TPU: https://amzn.to/2Sw3Oe8
CA Glue: https://amzn.to/2J8EvNW
CA Accelerator: https://amzn.to/3fpbycz
2830 Brushless motor: https://amzn.to/2J1CAdY
30amp ESC: https: //amzn.to/2EuBa9e
7 x 4.5 pusher propeller: https://amzn.to/35Zv0to
HS-40 Servo: https://amzn.to/3m3hnPi
2700mah 3S Battery: https://amzn.to/34ttPjJ
AR620 Receiver: https://amzn.to/3j4PbK4
DX6 Transmitter: https://amzn.to/3l6NFsD
3pin wire assortment: https://amzn.to/3l1xNYt
XT60 connector: https://amzn.to/3iyZWnf
5mm magnet: https://amzn.to/35ZPLoN
Screw assortment: https://amzn.to/2SvMxSs
2mm push rod ends: https://amzn.to/3nnjD4U
Z-Bend pliers: https://amzn.to/34mA0rt

*These are the settings I used for my JGMaker Magic 3D Printer with White Overture PLA. These settings are not going to work with every printer, or every PLA. Printers have different length bodin tubes, and PLA’s have different melting points. These may not work exactly for you, but should give you a good base to start with if you have a similar size printer. Good luck!

Profile 3 Cura Settings:
Quality:
Layer Height – 0.25
Line Width – 0.4
Shell:
Wall Line Count – 1
Infill:
Infill Density – 0
Material:
Printing Temperature – 210
Build Plate Temperature – 60
Flow – 100
Speed:
Print Speed – 100
Outer Wall Speed – 30
Inner Wall Speed – 30
Travel Speed – 80
Travel:
Enable Retraction – Checked
Retraction Distance – 4
Retraction Speed – 70
Retraction Extra Prime Amount – 0.7
Combing Mode – off
Cooling:
Enable Print Cooling – Checked
Fan Speed – 20
Mesh Fixes:
Union Overlapping Volumes – NOT Checked
Special Modes:
Surface Mode – Surface
Experimental:
Slicing Tolerance – Middle
