Turn Pictures Into CAD Models for Fusion 360
Автор: Christopher Lum
Загружено: 2021-03-29
Просмотров: 66315
Описание:
In this video we show how to convert an image (.jpg, .png, etc.) into a CAD model. In other words, this allows you to take a raster (AKA pixel-based) image and add it to your CAD model as a fully vectorized object.
Topics and timestamps:
0:00 – Introduction
0:30 – Workflow description
2:21 – Converting image to black and white using PowerPoint
5:59 – Converting image to black and white using GIMP
9:48 – Converting to a vector image using Inkscape
14:00 – Importing .svg into Fusion 360
17:25 – 3D printing object
18:25 – Cheat sheet of workflow/operations
Helpful tools
-GIMP (https://www.gimp.org/)
-Inkscape (https://inkscape.org/)
All Fusion 360 videos in a single playlist ( • Working with Fusion 360 )
#Fusion360
All 3D printing videos in a single playlist • 3D Printing
#3DPrinting
Please consider supporting the channel via Patreon at / christopherwlum , thank you!
