Hi friends welcome back to CADable. This is Engr. Ibrahim Omer. In this tutorial, we will model a coffee mug in solidworks. After sketching mug in solidworks, we will apply appearance to the model and render coffee mug. I hope you like it.

Chapters of the tutorial:

0:00 – Sketching circle on top plane
0:23 – Adding thickness using extrude boss
0:45 – Sketching handle for the cup
1:53 – Sketching elliptical profile
2:30 – Use of solid sweep feature
2:43 – Using fillet on the base of the cup
2:52 – Use of shell feature
3:13 – Using fillet on handle edges
3:25 – Using full round fillet on the top of the cup
3:40 – Applying appearance on the cup
3:53 – PhotoView 360 rendering in detail

It is a good exercise for beginners and it will be a good practice for beginners. Kindly use play pause technique for practice. Feel free to ask your queries in comment section. I will try to answer each and every question. Keep practicing as practice makes a man perfect.

For Files:
https://grabcad.com/library/coffee-mu...
