Audio amplifier using LM 386 IC
Автор: Gillani Data
Загружено: 2018-11-08
Просмотров: 142165
Описание:
LM386 Amplifier detail https://bit.ly/2znl7Vj
Single Transistor Amplifier https://bit.ly/31W538T
Two Transistor Amplifier https://bit.ly/2ol3keR
4440 IC Amplifier https://bit.ly/2z8c22q
low power amplifiers https://bit.ly/2orovw9
In this article we are going to show you a simple LM386 audio amplifier circuit. Circuit diagram of the LM386 based audio amplifier is shown in the given below diagram and animated picture. It is built by using popular amplifier LM386 (IC). We have used 8-ohm speaker, one-watt speaker, four electrolyte capacitors. We have used 6 volts power supply as power.
