D-Type Flip-Flop IC - 74HC74
Автор: Francis Studios Engineering
Загружено: 2024-04-21
Просмотров: 6649
Описание:
Fifth episode of my series by the name "CHIP CHAT" where we take a look at integrated circuits - on how they operate and how to use them.
In this episode we will check the building block of computing - a flip-flop IC and how can we utilize its capabilities.
[🏷️TAGS ]
#flipflop #d_type #74HC74 #74_series_logic
[⚠️ DISCLAIMERS ]
If you are following along this video, you are doing it at your own risk. Please always be very careful when experimenting with electricity and using tools and machinery.
[ ⭐CREDITS ]
To all my wonderful viewers :)
Timecodes
0:00 - Intro
2:18 - Datasheet
2:40 - Building The Circuit
5:05 - Explaining
6:51 - Toggle Mod
7:14 - Alternative IC
7:29 - Outro
