SCM DMC System T3C 1350 TSP Wide Belt Sander - J & G Machinery

Описание: J & G Machinery - Sanford, NC
A Div. of Wurth Baer Supply

⦁ Working width: 53"
⦁ Feed speeds: 6 to 52 FPM
⦁ "Pro-Sand" electronic touch screen control (with LCD 10.4" color display)
⦁ Constant pass line 900 mm from ground
⦁ Infeed reading bar for Epics sectioned pads pitch 32 mm
⦁ Unit one: Extractable internal cross belt sanding pad with linear blower with timed intervention for the sanding belt (Sanding belt dimensions: 150 x 4600 mm, Chevron belt: 140 mm x4430 mm) with PE 32T Epics electronic sectional pad – 18 HP variable speed with inverter
⦁ Unit two: Sanding pad with Epics PE 32/C electronic sectional pad pitch 32 mm, timed oscillating cleaning blowers – 20 HP variable speed with inverter
⦁ Unit three: Superfinish pad with PE 32/C Epics electronic sectional pad pitch 32 mm with 54" x 86" Chevron belt and timed oscillation cleaning blowers – 20 HP variable speed by inverter
⦁ Abrasive belt size for units Two and Three: 54" x 103"
⦁ Panel cleaning unit at machine outfeed with timed rotating cleaning blowers
⦁ Vacuum bed with 5 HP blower integrated inside machine frame
⦁ Motorized infeed rollers feeding conveyor
⦁ Motorized outfeed rollers
⦁ 5 HP feed motor driven by inverter
⦁ All units have total management of its functionality by "Pro-Sand" electronic control
⦁ Dust collection requirements: 4,662 CFM
⦁ Electrical requirements: 105 amps on 480 volt
⦁ Machine weight: 9,600 lbs.
