IR Proximity Sensor Based Counter Circuit Using 7 Segment Display by INVENTIVE TECHNICAL SUPPORT

Описание: In this video, I have made a Project which is IR Proximity Sensor Based Digital Counter Using 7 segmant Display. This project can be used for RPM ( Rotation Per Munite) Counter.
In my video, I have used one 7 Segment Display but you can use multiple 7 segment display, just by increasing the amount of 4026 IC

If you like to see my video then Please SUBSCRIBE to my channel & click the bell icon to be the first to see Electronics Project.Share with friends and family. Please comment for more information about Electronics Project.

This circuit can be easily made at home. You can made it too. It take some components to make it which I used.

1. 4026 IC
2. LM 358 IC
3. 7 Segment Display (Comon Cathode)
4. 330 ohm, 10 K Ohm, 1 K Ohm Resistor
5. IR LED
6. IR Receiver
8.10 K Potentiomeater
9.Some jumper wire
10.Bradeboard
11. Battery (9 V)

Circuit Diagram : https://drive.google.com/file/d/1dJT-...
