Introduction of Electroluminescent Lamp # EL panel # EL Backlight # Cochief Industrial company
Автор: 呂宜家
Загружено: 2015-07-23
Просмотров: 10731
Описание:
An electro luminescent lamps electrically similar to a capacitor two conducting surfaces (light-emitting phosphor layer) with a dielectric layer between. Electroluminescent lamps illuminate when powered with AC power. As voltage is applied to the conductive surfaces, an electric field is generated across the phosphor anddielectric layers. Twice during each cycle electrons are excited and emittedlight through the transparent front electrode.
The basic building block for the Electroluminescent lamp is aluminum foil. Serving as the back electrode, the foil has dielectric coating applied to give the lamp high voltageintegrity. A layer of light emitting phosphor is then applied. Screened onto thephosphor is the transparent front electrode, which defines the lit area. On top ofthe electrode an opaque bus bar is screened, to provide a more uniform electricfield across the entire lamp surface, insuring more uniform luminance. Frontand back leads, specially treated to insure the moisture barrier is notcompromised, are applied to provide power access. Finally, the entire sandwichis enclosed in an Aclar package to protect the lamp from exposure toenvironment, especially moisture, and to provide electric insulation.
To see more about EL product, please come to our official website http://www.cochief.com/ www.facebook.com/cochief.EL
