Do Motion with the Micro820 PTO Pulse Train Output Instruction
Автор: Tim Wilborne
Загружено: 2022-01-01
Просмотров: 14036
Описание:
Output 6 of an Allen Bradley 2080-LC20-20QBB Micro820 PLC can be used for a Pulse Train Output.
In this lesson we go through how to configure the PTO instruction in Connected Components Workbench so that the Pulse Train Output is the "pulse" of a stepper driver and give it an external direction to operate a stepper motor.
Not sure what video to watch next? Enhance your skills and track your progress at https://controls.tw/yt-courses!
Items used in this video:
PLC Trainer https://controls.tw/yt-plc-trainers
Stepper Trainer https://controls.tw/steppertrainer
The above links make these videos possible. Please use them!
Support these videos while you advance your skills https://controls.tw/yt-courses
