How to Use Custom Features for Wiring in Onshape - Tech Tip
Автор: Onshape
Загружено: 2025-04-08
Просмотров: 3877
Описание:
Add the highlighted Cable/Wire Routing Onshape Custom Feature - https://cad.onshape.com/documents/359...
Here are six easy steps for defining wire and cable harness design natively inside of Onshape.
This suite of wiring custom features combines the best capabilities from previous iterations into an integrated workflow that supports the entire wiring process. It allows you to import wire data directly from 2D electrical schematic software via CSV files, manage cable and wire routing efficiently through 3D space, and generate accurate wire length tables.
Check out the full guide on Wire Routing Custom Feature in Onshape - • Wire Routing Custom Feature
